eCTG-8M Wireless Fetal Monitor
Inquire now

The eCTG-8M Wireless Fetal Monitor is a compact wireless cardiotocography system designed for continuous monitoring of fetal heart rate (FHR) and uterine contractions (TOCO) during pregnancy and labor. The system uses wireless ultrasound and TOCO probes to transmit monitoring data, allowing greater freedom of movement for the mother while maintaining continuous fetal surveillance. Its wireless architecture can also be integrated into a centralized monitoring network for multi-bed and multi-ward obstetric care.

Features & Benefits

  • Wireless fetal monitoring using ultrasound and TOCO probes
  • Fetal heart rate (FHR) monitoring
  • Uterine contraction (TOCO) monitoring
  • Supports twin pregnancy monitoring
  • Built-in speaker for real-time fetal heart sounds
  • High-resolution color display on the wireless probes
  • Displays patient identification, battery status, and bed number
  • Approximately 20-meter open-space wireless communication range
  • Water-resistant probes suitable for water-birth environments
  • Rechargeable Li-ion batteries for extended operation
  • Bluetooth 4.0 wireless communication
  • 2.0 MHz multi-crystal, wide-beam pulsed-Doppler ultrasound transducer
  • TOCO measurement range of 0–100
  • Compact 0.96-inch OLED display with 128 × 64 resolution
  • Continuous operating mode
  • Central monitoring capability for up to 32 fetal monitoring beds
  • Automated CTG scoring including Fischer, Krebs, NST, and ACOG scoring
  • Supports HIS and EMR integration

Clinical Application

The eCTG-8M is intended for antepartum and intrapartum fetal monitoring, including non-stress testing from approximately the 28th week of pregnancy. It is used to continuously assess fetal heart rate and uterine activity during pregnancy and labor, supporting the evaluation of fetal well-being and detection of potentially concerning fetal heart-rate patterns. The system is suitable for antepartum examination rooms, labor and delivery rooms, maternity units, and obstetric monitoring departments, including environments where maternal mobility and water-birth monitoring are required.
